| ASTM D-3441 | |||
| For determining cone resistance and friction resistance of soil layers. | |||
| Max driving capacity | : 10.000 kg | ||
| Max pulling capacity | : 15.000 kg | ||
| Stroke of cylinder | : 1250 mm | ||
| Sonding speed | : 2 cm/sec | ||
| TT-700.1 | Hydraulic driving appliance | Steel construction, hydraulic operated 10 tons capacity | 1 Set |
| TT-700.2 | Engine pump | The power unit is driven by a 8 kw petrol engine. | 1 Set |
| TT-700.3 | Sounding Rod | Machined steel, 36 mm o.d., 1 mtr effective length, tappered thread | 20 Pcs |
| TT-700.4 | Plunger Rod | Round bar, 15 mm dia, 1 mtr length | 20 Pcs |
| TT-700.5 | Adaptor | ||
| Consist of | |||
| TT-700.5.1 | Push Adaptor | Machined steel | 1 Pc |
| TT-700.5.2 | Pull Adaptor | Machined steel | 1 Pc |
| TT-700.6 | Spiral Anchor | ||
| Consist of | |||
| TT-700.6.1 | Spiral Anchor | Machined steel, elded 1.5 mtr length | 4 Pcs |
| TT-700.6.2 | Handle and T-piece | Machined steel, welded | 1 Set |
| TT-700.7 | Mantel cone | Precision machined steel, hardened, tappered thread, 60o angle, Ø 35.7 mm | 1 Pc |
| TT-700.8 | Friction cone | Precision machined steel, hardened, with friction jacket, tappered thread, 60o angle, 35.7 mm dia. | 1 Pc |
| TT-700.9 | Wrenches Set | Pile wrench (2), adjustable wrench (1), spanner wrench (1), allen key (1), screw driver (1), oil can (1), steel brush (1), piston wrench (1), seals tape (2), oil seals (2), steel box (1) | 1 Set |
| TT-700.10 | Fasten Press | Beam Cannal | |
| Consist of | |||
| TT-700.10.1 | Long Fasten Press | 1.5 mtr length, 8 cm width | 2 Pcs |
| TT-700.10.2 | Short Fasten Press | 30 cm length, 12 cm width | 2 Pcs |
| UM-671 | Manometer | 150 kg/cm2 capacity | 1 Pc |
| UM-677 | Manometer | 1000 kg/cm2 capacity | 1 Pc |
